ELASTOSIL® E43
Properties Uncured
|
Property
|
Condition
|
Value
|
Method
|
|---|---|---|---|
| Color | - | transparent | - |
| Density | 20 °C | 1.09 g/cm³ | DIN EN ISO 2811-1 |
| Viscosity, dynamic D = 0.5 1/s | 25 °C | 250000 mPa·s | DIN EN ISO 3219 |
| Viscosity, dynamic D = 25 1/s | 25 °C | 175000 mPa·s | DIN EN ISO 3219 |
| Skin formation time[1] | - | 10 min | - |
| Curing time | 23 °C | 50 % r.h | 12 h/mm | - |
These figures are only intended as a guide and should not be used in preparing specifications.
Curing Conditions: 14 days at 23 °C and 50 % rel. humidity, 2 mm sheet, no post-curing
|
Property
|
Condition
|
Value
|
Method
|
|---|---|---|---|
| Color | - | transparent | - |
| Density in water | 23 °C | 1.10 g/cm³ | DIN EN ISO 1183-1 A |
| Hardness Shore A | - | 30 | DIN ISO 48-4 |
| Tensile strength[1] | - | 6.50 N/mm² | ISO 37 type 1 |
| Elongation at break[2] | - | 500 % | ISO 37 type 1 |
2 Type 3 / 23°C / 2mm
These figures are only intended as a guide and should not be used in preparing specifications.
Disclaimer
All the information provided is in accordance with the present state of our knowledge. Nonetheless, we disclaim any warranty or liability whatsoever and reserve the right, at any time, to effect technical alterations. The information provided, as well as the product's fitness for an intended application, should be checked by the buyer in preliminary trials. Contractual terms and conditions always take precedence. This disclaimer of warranty and liability also applies particularly in foreign countries with respect to third parties' rights.
| Colour: | Black, Translucent |
|---|---|
| Crosslinker type: | E – Acidic (acetic acid) |
| Max. temp. °C: | 180°C |
| Properties: | High mechanical strength |
| Shore A: | 30 |
| Silicone product groups: | Adhesives / sealants |
| Viscosity [mPa·s] D=0.5–1 1/s: | 200'000 - 300'000 |
accessories
- 310ml cartridges
- 310ml bag
- flexible working
- Flame coating device
- Effective and cost-effective
- Can be used for almost all materials
- Gentle on materials in terms of temperature
- purity 99 %
- readily soluble in water
- improves the adhesion of
- RTV-1 silicone rubber
- Application for metals or plastics.
